Poolsana InverPOWER ULTRA 18 kW inverter heat pump for pools
€1900.00 incl. VAT
Full-inverter heat pump for pools up to approx. 70 m³ – up to 18.1 kW of heat and COP up to 18.07.
- Mitsubishi rotary compressor and titanium heat exchanger
- Control from the display or via an app (WiFi)
- BOOST, SILENCE and SMART modes
- Included: winter cover, feet, condensate hose
Poolsana InverPOWER ULTRA 18 kW inverter heat pump for pools
The ULTRA 18 kW Poolsana InverPOWER ULTRA full-inverter heat pump is designed for pools up to approx. 70 m³. It delivers up to 18.1 kW of heat at a consumption of 0.27 to 2.81 kW. The coefficient of performance (COP) reaches 18.07.
| Manufacturer | Poolsana |
|---|---|
| Series | InverPOWER ULTRA |
| Heat output | up to 18.1 kW |
| COP | up to 18.07 |
| Power consumption | 0,27–2,81 kW |
| Recommended pool volume | up to 70 m³ |
| Power supply | 1 N / 230 V |
| Refrigerant | R32 |
| Connection | ∅ 50 mm |
| Control | LCD display and app (WiFi) |
High efficiency with a full inverter
The compressor and the fan are regulated smoothly by speed. This way the heat the heat pump delivers is many times greater than the electricity it draws from the mains. The compressor is a Mitsubishi rotary compressor. The titanium heat exchanger is resistant to chlorinated and salt water.
What the ULTRA 18 kW heat pump offers
- Three operating modes: heating, cooling and automatic mode.
- Three power modes: BOOST for the fastest heating, SILENCE for the quietest operation and SMART for automatic adjustment.
- Control from the built-in LCD display with touch buttons or via a free app for iOS and Android (WiFi).
- Real-time clock, timer and display of the set and the measured temperature.
Safety and design
The housing is made of black protectively lacquered metal. The air outlet grille is cut directly into the housing, so the heat pump looks elegant.
A pressure gauge shows the working pressure of the R32 refrigerant. High- and low-pressure switches and a water flow sensor make operation safe. If the water stops flowing, the heat pump switches off automatically.
Installation and connection
The heat pump is connected via a bypass in the pressure pipe of the filtration circuit. The ports have a 1 1/2″ internal thread. The kit includes two fittings with a 1 1/2″ external thread for ∅ 50 mm pipe.
The pool pump must deliver at least 7.7 m³/h. It is better if it is 1–2 m³/h more powerful.
The power cable is 3-core. On site it can be extended and the heat pump connected directly to the electrical panel. This and all other electrical installation work must be carried out only by an electrician.
The heat pump is installed after the filter but before any water treatment system. With salt electrolysis, the salt concentration must not exceed 0.5 % (5 g/l).
Which pools it is suitable for
The recommended volume of up to 70 m³ is conservative. If your pool is close to this limit, consider the next higher output. This way you will also have a reserve on days with colder air. A winter cover, vibration-absorbing feet and a condensate drain hose are included in the kit.
Technical data
- Heat output: up to 18.1 kW at air 27 °C and up to 13.35 kW at air 15 °C.
- Power consumption: 0.27–2.81 kW; COP up to 18.07.
- Power supply: 1 N / 230 V; max. current 17.7 A; fuse 20 A.
- Noise: 43–53 dB(A) at 1 m and 23–33 dB(A) at 10 m.
- Operating range: from −10 to +43 °C; connection ∅ 50 mm.
- Dimensions: 980 × 400 × 660 mm.
Questions about choosing or installing?
Write to us or give us a call – we will help you choose the right model for your pool.
